HDMI Extender 4K 120m over Ethernet + KVM
HDMI Extender 4K 120m over Ethernet + KVM
SKU:HA-HE4K120M-KVM
Regular price
£75.67 GBP
Regular price
Sale price
£75.67 GBP
Taxes included.
Shipping calculated at checkout.
In stock
Couldn't load pickup availability
- Support HDMI 1.4/HDCP1.4
- Support local loop-out
- Support 120m long distance transmission
- Low power consumption, low temperature and high safety
- Both the TX and RX support 3.5MM left and right audio output
- Support IR control
- Support USB mouse and keyboard extension
Technical Specifications
Model: HA-HE4K120M-KVM
| Length of CAT5e/CAT6 cable between Rx and TX | 120 meters |
| HDMI Input | 4k/1080p/720p/576p/576i/480p/480i |
| HDMI Output | 4k/1080p/720p/576p/576i/480p/480i |
| Max bandwidth | 340MHz |
| Max baud rate | 3x3.4Gbps |
| Input video signal | 0.5~1.5Volts p-p |
| Output DDC signal | 5Volts p-p (TTL) |
| Input HDMI cable distance | ≤10m AWG26 HDMI standard cable |
| Output HDMI cable distance | ≤10m AWG26 HDMI standard cable |
| TX Max working current | 350mA |
| RX Max working current | 200mA |
| Power Adapter Format Input | AC (50HZ, 60HZ) 100V-240V |
| Power Adapter Format Output | DC5V/1A |
| Operating Temperature range | (-15 to +55℃) |
| Operating Humidity range | 5 to 90%RH (No Condensation) |
| Dimension (L x W x H) | 107x105x27.3 (mm) |
| TX Weight | 499g |
| RX Weight | 494g |
| Package Includes | 1. TX Extender 1pcs. 2. RX Extender 1pcs. 3. IR cable 1pair. 4. 12V/2A DC Power adapter 2pcs. 5. User Manual 1pcs |
